Making progress! 344 unrouted. Definitely getting tight, I may have to delete a few of the test points or shrink things in a bit, but I think I can pull it off. It's been a while since I've done a high density 4 layer board instead of my more recent usual 10L with ViP.

KiCAD 3D render of the top side of a dense PCB with connectors along the south side, two BGAs in the north center and east, and a SFP+ cage in the southwest
Underside of the same PCB showing dense trace routing covering much of the back side, plus a significant number of passives down to 0201 size
