Experimental Validation of HomHBFEM Simulations of Fast Corrector Magnets for PETRA IV
Jan-Magnus Christmann, Laura Anna Maria D'Angelo, Herbert De Gersem, Sven Pfeiffer, Sajjad Hussain Mirza, Adeel Amjad, Lucas Rousselange, Matthias Thede
https://arxiv.org/abs/2602.14824 https://arxiv.org/pdf/2602.14824 https://arxiv.org/html/2602.14824
arXiv:2602.14824v1 Announce Type: new
Abstract: This paper presents experimental validation of the homogenized harmonic balance finite element method (HomHBFEM), which we have developed as a dedicated simulation technique for magnets with fast excitation cycles, in particular the fast corrector (FC) magnets for PETRA IV at DESY. The HomHBFEM allows efficient three-dimensional nonlinear eddy-current simulations of laminated magnets at elevated frequencies with a relatively coarse finite element (FE) mesh and without computationally expensive time-stepping. This is achieved by combining a frequency-domain-based homogenization technique with the harmonic balance FE method. The simulation results for the magnetic flux density along the axis of the FC magnets as a function of frequency and the resulting integrated transfer function (ITF) are compared to Hall probe and search coil measurements of the first prototype FC magnet for PETRA IV. A good agreement between simulated and measured ITFs is achieved for excitation frequencies from 10 Hz to 10 kHz.
toXiv_bot_toot
Ball Magnets
Three of the AFL's Best, Tom Mitchell, Patty Cripps, and Lachie Neale are joined alongside some of the games most interesting players and personnel...
Great Australian Pods Podcast Directory: https://www.greataustralianpods.com/ball-magnets/
Samsung Galaxy S26 and S26 Plus review: bigger battery and seven years of software updates, but basic cameras, few major updates, and no Qi2 charging magnets (Dominic Preston/The Verge)
https://www.theverge.com/tech/892311/samsung-galaxy-s26…
Cryogenics and the use of superfluid helium in high-energy particle accelerators (1980-2000)
Philippe Lebrun
https://arxiv.org/abs/2602.14298 https://arxiv.org/pdf/2602.14298 https://arxiv.org/html/2602.14298
arXiv:2602.14298v1 Announce Type: new
Abstract: The period 1980-2000 saw the impressive development of applied superconductivity in high-energy particle accelerators, from single components to long strings of superconducting magnets and high-frequency acceleration cavities. Large and powerful cryogenic systems were designed ancillary to superconducting devices operating generally close to the normal boiling point of helium, but also above 4.2 K in supercritical and below 2 K in superfluid. Low-temperature operation in accelerators also involves considerations of ultra-high vacuum, limited stored energy and beam stability. We recall the rationale for cryogenics in high-energy particle accelerators and review its development over the period of interest, with reference to the main engineering domains of cryostat design and heat loads, cooling schemes, efficient power refrigeration and cryogenic fluid management. In view of its importance and novelty, a specific section is devoted to the developments that led to the LHC at CERN.
toXiv_bot_toot
Application of RFSoC Technology for Beam Position Monitors at the SuperKEKB Storage Rings Injection Points
B. Urbschat, G. Mitsuka, L. Ruckman
https://arxiv.org/abs/2602.14870 https://arxiv.org/pdf/2602.14870 https://arxiv.org/html/2602.14870
arXiv:2602.14870v1 Announce Type: new
Abstract: In order to achieve its ambitious luminosity target, the SuperKEKB collider must achieve and sustain high beam currents on the order of Ampere in its storage rings. This requires continuous top-up injection and operation with a two-bunch injection scheme, injecting two 96 ns spaced bunches in a single injection cycle. An important input for tuning the injection beam is the position reading from a dedicated beam position monitor (BPM), located after the septum magnets, slightly upstream of where the injected and stored beams converge. Previously, the readout electronics used for these special BPMs were not capable of independent measurement of both bunches in the two-bunch injection mode and modification of the concerned devices and their firmware was not feasible. The opportunity was taken to develop a new readout device based on the AMD/Xilinx RF System on a Chip (RFSoC) platform with the goal of not only providing a sufficiently flexible and performant readout solution for the concerned BPMs, but also to evaluate and gain experience with the platform for beam monitor electronics applications. This paper is concerned with the details of this development as well as evaluation and operation of the developed device.
toXiv_bot_toot
Conventional Accelerator Magnets
Stephane Sanfilippo
https://arxiv.org/abs/2602.19808 https://arxiv.org/pdf/2602.19808 https://arxiv.org/html/2602.19808
arXiv:2602.19808v1 Announce Type: new
Abstract: This course introduces conventional magnets used in particle accelerators, focusing on both normal-conducting copper coil magnets and permanent magnets (PMs). It covers magnet classification, design principles, material selection, and mechanical constraints. Advantages and limitations of PMs compared to copper coil magnets are discussed. Key construction steps and cooling methods are presented. The course also includes magnetic field measurement techniques and quality control. Practical examples from PSI and CERN illustrate the concepts.
toXiv_bot_toot
Superconducting Accelerator Magnets
Stephane Sanfilippo
https://arxiv.org/abs/2602.19830 https://arxiv.org/pdf/2602.19830 https://arxiv.org/html/2602.19830
arXiv:2602.19830v1 Announce Type: new
Abstract: This course introduces key aspects of superconducting magnet technology in accelerators: basic principles, superconducting materials (NbTi, Nb$_3$Sn, ReBCO), wire and cable architectures, and fabrication methods. Compared to copper or permanent magnets, superconducting systems require cryogenics and complex protection schemes but enable superior performance. Core challenges - like flux pinning, magnetization effects, quench behavior, mechanical forces interception, power tests and magnetic measurements - are addressed through examples of magnets from PSI and CERN.
toXiv_bot_toot
