PIC12F683 full die image after wet chemical delayer to (approximately) polysilicon layer. There's a few areas in the right and bottom right that are overetched to substrate and a few spots in the analog and power rings that still have some M1 and even M2 remaining.
These are both full resolution scans with 20x/0.42 and 100x/0.90 objectives.
It's interesting to note how some features (most notably the silicon substrate in the overetched areas) are *more* visible in the low…
