Making a new test board that I had hoped to finish tonight but got distracted by some other stuff...
Anyway, it's a STM32H750 as a peripheral for my Trion T20 devkit, hanging off one of the three 0.1" GPIO headers.
The board will have the MCU, an extra QSPI flash for additional firmware storage, a MAC address EEPROM in case I decided to add Ethernet later on, and a 25 MHz oscillator plus some LEDs.
Nothing super fancy, main goal is to validate my base support schem…
