Flux Trapping Characterization for Superconducting Electronics Using a Cryogenic Widefield NV-Diamond Microscope
Rohan T. Kapur, Pauli Kehayias, Sergey K. Tolpygo, Adam A. Libson, George Haldeman, Collin N. Muniz, Alex Wynn, Nathaniel J. O'Connor, Neel A. Parmar, Ryan Johnson, Andrew C. Maccabe, John Cummings, Justin L. Mallek, Danielle A. Braje, Jennifer M. Schloss

Flux Trapping Characterization for Superconducting Electronics Using a Cryogenic Widefield NV-Diamond Microscope
Magnetic flux trapping is a significant hurdle limiting reliability and scalability of superconducting electronics, yet tools for imaging flux vortices remain slow or insensitive. We present a cryogenic widefield NV-diamond magnetic microscope capable of rapid, micron-scale imaging of flux trapping in superconducting devices. Using this technique, we measure vortex expulsion fields in Nb thin films and patterned strips, revealing a crossover in expulsion behavior between $10$ and $20~μ$m strip…
